Vision 1000 Product Specifications

Vision 1000 Recorded Parameters

Parameter Unit Rate Resolution Accuracy
Latitude degrees 4 Hz 1×10-7 deg 2.5 m CEP 2σ
Longitude degrees 4 Hz 1×10-7 deg 2.5 m CEP 2σ
Altitude (GPS) meters 4 Hz 1 mm 5m SEP 2σ
Ground Speed* knots 4 Hz * < 5 knots **
Vertical Speed* feet/minute 4 Hz * < 50 ft/min **
Heading* degrees 4 Hz * < 2 deg 1σ
Pitch Altitude* degrees 4 Hz * < 1.5 deg 1σ
Roll Attitude* degrees 4 Hz * < 1.5 deg 1σ
Pitch Rate deg/second 4 Hz 0.01 deg/sec 1 deg/sec/sqrt(Hz)
Roll Rate deg/second 4 Hz 0.01 deg/sec 1 deg/sec/sqrt(Hz)
Yaw Rate deg/second 4 Hz 0.01 deg/sec 1 deg/sec/sqrt(Hz)
Normal Acc. g forces 4 Hz 0.9 ug 10 mg 2σ
Longitudinal Acc. g forces 4 Hz 0.9 ug 10 mg 2σ
Lateral Acc. (slip) g forces 4 Hz 0.9 ug 10 mg 2σ

Audiovisual Specifications

Image Resolution 2 MP @ 4 Hz
Image Frame Rate 4 Hz
Audio Frequency Range 50 Hz – 15 kHz

MEMS Rate Gyroscopes

Sense Axis X, Y, Z
Dynamic Range 300°/s
Sample Rate 64 Hz

MEMS Accelerometers

Sense Axis X, Y, Z Quad Redundant
Range ±10 g and ±1.7 g
Resolution 5 mg
Sample Rate 64 Hz

Removeable Flash Memory

Storage Capacity 16 GB
Storage Time 4 hours image/audio, 200+ hours inertial
Card Type SD HC

GPS Specifications

GPS Receiver Type L1 Frequency, C/A Code, 16 Channels
GPS Update Rate 4 Hz
GPS TTFF* 2 min
Signal Reacquisition < 1 s
GPS Dynamics 4 g
Antenna Frequency 1575.42MHz ± 2MHz
Polarization RHCP
Antenna Dimensions 1.9” X 2.3” X 0.6”

General Specifications

Input Supply Voltage 14.0 – 32.0 VDC
Input Supply Current 100 mA
Weight 8.8 oz
Dimensions 4.02” x 2.08” x 2.48”
Roll and Pitch Accuracy < 1.5° RMS
Yaw Accuracy < 2.0° RMS
GPS Accuracy 2.5 m CEP, 5.0 m SEP
Operating Temperature -40°C to + 70°C

On Board Flash Memory

Storage Capacity 8 GB
Storage Time 2 hours image/audio, 200+ hours inertial
